JBL MA-9100HP
9.2-channel 8K High Performance AV Receiver
9.2-channel 8K High Performance AV Receiver
9.2-channel 8K High Performance AV Receiver
JBL MA-9100HP 9.2 Channel AVR
The JBL MA9100HP is a high-performance AV Receiver that delivers stunning realism with the latest 8K HDMI specifications and native 9-channel decoding of immersive audio from Dolby Atmos and DTS:X for the ultimate home cinema experience. Seamlessly integrate your smart TV or projector with 6 HDMI inputs and 2 outputs, plus eARC. It is designed with a passion for music and movies, bringing both to life with true high fidelity. The MA9100HP features nine channels of low noise Class D amplification for real world power to all channels. In addition to the onboard Moving Magnet phono input for connecting a turntable, additional music content can be accessed immediately with integrated streaming using Apple Airplay2, Google Chromecast, and Bluetooth AptX Adaptive. Taking performance to the next level, the MA9100HP comes “Dirac Live Ready” for automatic room correction, assuring audiophile-quality sonics and allowing integrators and power-users to optimize the system to their personal room acoustics. Featuring a secondary HDMI video output and audio Zone, content can be made available in a secondary location. In addition to physical controls, the MA9100HP allows for IP control for third party control system integration.
SPECS & DOWNLOADS
-
HDMI eARC - Yes
HDMI Audio Return Channel - Yes
8K HDMI input connectors (HDMI 2.1, HDCP 2.3 up to 8K/60Hz, 4K/120Hz) - 3
HDMI 2.1 enhanced gaming features - Gaming-VRR, ALLM, QFT, HFR (4K@120Hz)
HDR 10+, Dolby Vision - Yes , Yes
File format - File format up to 48 kHz / 320kbps WMA MP3 / MPEG-4 AAC
Pure Analog - Yes
EZ Set EQ - Yes
Front channel bi-amp - Yes
Digital signal processing - up to 24-bit/192kHz
Mains voltage - 110 – 240V, 50–60Hz
Max. power consumption - 900W
Standby power consumption - <0.5W
-
Channels - 9.2
FTC Rated Output Power (20Hz– 20kHz, 2 channels driven, 1% THD max, 8Ω) - 140W
Rated Power @ 8Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max) - 140 W RMS
Rated Power @ 4Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max) - 240 W RMS
-
Dimensions incl. feet and speaker terminals (H x W x D) - 5.3" x 17.0" x 15.6" (135.0mm x 432.0mm x 396.4mm)
Weight - 16.8lb (7.6kg)
-
HDMI Input/Output - 6/ 2
Wi-Fi - Yes (2.4/5GHz)
Bluetooth receiver - Yes (v5.3, Low Energy, APTX HD, APTX Adaptive)
Bluetooth transmit - Yes
Digital Audio Input - 1 Coax, 1 Optical, 1 USB
Stereo analog input - 2 single-ended RCA (line level), 1 Moving Magnet Phono input + Ground
Pre-Out (single ended RCA) - Stereo Zone 2, Subwoofer 1, Subwoofer 2
Ethernet - RJ45 Gigabit, WiFi Onboard
-
1x IR Remote
2x AAA batteries
1x Bluetooth antenna
2x Wi-Fi antenna
1x Power Cord
1x Quick-Start Guide
1x Safety Sheet
